ABB BC810K01

ABB BC810K01

Product information：

Brand：ABB                             Model number：BC810K01

Condition：new                              Warranty: 12 month

Lead Time：3-day working da        Country of origin: Sweden

Price: Please contact us                   Product weight：0.45kg

HS: 8517623990

Product technial information：

ABB BC810K01 Product Details

The ABB BC810K01 is a CEX-bus interconnection unit designed for the AC 800M system. It facilitates the connection and communication between various components within the automation system. The unit consists of a baseplate (TP857) and a power supply/logic board, and it is supplied with a CEX-Bus terminator (TB850).

Product Parameters:

• Product ID: BC810K01

• ABB Type Designation: BC810K01

• Order Number: 3BSE031154R1

• Dimensions (W x H x D): 59 mm x 185 mm x 127.5 mm

• Weight: Approximately 0.6 kg to 0.77 kg (depending on the source)

• Operating Voltage: 24 VDC

• RoHS Status: Compliant with EU Directive 2011/65/EU

• Mounting: DIN-rail mounting via the baseplate

• Communication Interface: CEX-Bus

Product Advantages:

• Seamless Integration: Specifically designed for ABB's AC 800M system, ensuring efficient connectivity between components.

• Enhanced Availability: Can divide the CEX-Bus into separate segments, improving availability in systems with redundant communication interfaces.

• Redundancy Support: Supports redundant communication interface units.

• Online Replacement: In a fully redundant system with interlinked BC810 units and a primary/backup CPU pair, the CPU baseplate can be replaced online without disrupting CEX traffic.

• Robust Design: Designed to withstand demanding industrial environments, ensuring long-term performance.

• Modularity and Scalability: Integrates into various ABB automation systems, offering flexibility for system expansion.

• Easy Installation: The inclusion of the TP857 baseplate facilitates secure and straightforward mounting.

• Reliable Operation: Comes with the TB850 CEX-Bus Terminator for dependable operation.

Precautions:

• Ensure proper grounding of the baseplate to the DIN-rail using the metal parts of the housing.

• When replacing the BC810 unit itself, all traffic to the connected CEX segment will be stopped.

• Refer to the specific product documentation and safety guidelines provided by ABB for detailed installation and operation precautions.

• Ensure that the power supply is within the specified operating voltage range.

• Adhere to EMC and Low Voltage Directives as specified in the product documentation.

Product Applications:

The ABB BC810K01 CEX-bus interconnection unit is primarily used within the ABB AC 800M automation system to:

• Facilitate communication and data exchange between various modules and devices on the CEX-Bus.

• Extend the on-board communication ports with communication interface units.

• Implement redundant communication interfaces on the CEX-Bus.

• Increase the availability of the CEX-Bus by dividing it into separate segments, particularly beneficial in systems with redundant communication interfaces.

• Connect CPUs (like PM861A, PM862, PM864A, PM865, PM866, PM866A, and PM867) to the CEX-Bus.

• Enable online replacement of the CPU baseplate in redundant configurations.

Delivery information：

Shipping Port: Xiamen, China

Payment: Bank of Chicago, Bank of Singapore

Transport: In Stock Ready for Shipment via DHL, TNT, FEDEX, UPS, ARAMEX and etc

Express cooperation: fedex, DHL, UPS and your express account

Service: Professional Sales provides 24 hours /7 days online service

Welcome, thank you for your trust, The seller has more than $1526000 worth of industrial control products inventory.hope we can help you solve your problem!!!  We Can transport to the world!!!
